Anyone Familiar with "Air Ace" Compressors?

I was driving through the neighborhood this past weekend, and there it was by the curb, with a "Free to Good Home" sign: an air compressor. The gentleman was still in his garage, said it worked fine, and that he had upgraded to a bigger unit.
So I threw (well, it was a little heavy to throw but...) this "Air Ace TD2525" into the back of my Element, and now it sits in my garage. It's somewhat bigger than my existing compressor, so perhaps it's an upgrade.
The problem is that I have no documentation, and to my surprise there are very few hits, and no relevant ones, on Google. One guy complained that it uses oil very rapidly. I'm not even sure how much of what oil to add, or even where to add it.
Is anyone perhaps familiar with this obviously Chinese product, enough to give some basic "how to get started" verbiage?
Art
Add pictures here
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

Is it oil-less, perhaps?? Proly not, if it's belt-drive, altho even some direct-drive units use oil. If oil, you should be able to find a a drain plug at the base of the compressor head, proly a 1/4-3/8 pipe thread, with a square, hex or allen head? No dip stick?
If there is no dip stick and no fill, and only a drain plug, you can make a fill with a short nipple, an elbow, and mebbe another short (vertical) nipple, which then serves to establish the oil level in the compressor head. What this level should be is a bit of a question, but it proly isn't much higher than 1" from the base.
There was a discussion on rcm as to what the diff between motor oil and compressor was. The only thing I notice is that compressor oil is clear, and proly doesn't have to withstand as high a temp as motor oil, which suggests motor oil would be OK.... another good Q for rcm.
--
EA


>
> Art
  Click to see the full signature.
Add pictures here
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
Existential Angst wrote:

2.5 HP direct drive runs at 2850 rpm 25 gallon tank. Made by Taizhou Changou Electro-Machinery Co., Ltd. oil lubricated,
Should use common air compressor oil and have a sight glass to show you the level. You add oil through the crankcase breather on the back of the unit. (black plastic item on the top of the rear cover casting)
--
Steve W.

Add pictures here
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

RCM does it again! And to think that some ahr peeple disapprove of crosspoting to rcm.... can you imagine???
--
EA


>
> --
  Click to see the full signature.
Add pictures here
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload

Unlike AMC, there are still a few on topic threads at RCM <VBG>
Karl
Add pictures here
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
On 1/5/2012 3:30 AM, Existential Angst wrote: ...

The most basic difference is compressor oil is ND. Do _NOT_ use a HD motor oil in a compressor. There are many other details in differences in additives to address the specific differences in the applications--pressure, foaming, water, etc., etc., etc., ... All in all, one might as well use an oil formulated for the purpose instead of hoping something else is adequate.
--
Add pictures here
<% if( /^image/.test(type) ){ %>
<% } %>
<%-name%>
Add image file
Upload
OK, so people read this, and conclude we can use North Dakota oil. But what is HD oil? I happen to know the difference between ND and HD, (HD is heavy duty; j/k) but it would be kind of you to explain your terms for the new readers, here.
Christopher A. Young Learn more about Jesus www.lds.org .
The most basic difference is compressor oil is ND. Do _NOT_ use a HD motor oil in a compressor. There are many other details in differences in additives to address the specific differences in the applications--pressure, foaming, water, etc., etc., etc., ... All in all, one might as well use an oil formulated for the purpose instead of hoping something else is adequate.
